Nintendo Switch 2 HDR Disappoints Despite New Support

June 19, 2025

2 min read

The Nintendo Switch 2 includes HDR support for both handheld and docked modes, which initially seemed promising. However, its implementation falls short of expectations. In handheld mode, you have an edge-lit LCD screen with limited HDR capability, as it has a peak brightness of around 450 nits. Unlike OLED panels, LCDs’ infinite contrast is a bit too constrained for a heavy HDR display.

Nintendo Switch 2 HDR Criticized for Poor Calibration and Display Limitations, Here’s How to Fix It

Docked mode has no such hardware limitations, as it uses an external monitor, but poorly implemented calibration features. Vincent Teoh of HDTVTest, one of the most well-respected experts on display tech, just took a deep dive into the console’s HDR output. His results suggest several calibration problems. HDR performance on the Switch 2 varies significantly depending on whether the connected display supports HGIG (HDR Gaming Interest Group) or source-based tone mapping.

The system’s HDR adjustment menu also lacks user-friendly features—there are too many steps and no numeric indicators, unlike on PlayStation or Xbox consoles. Another problem lies in the default paper white setting, which exceeds the 203-nit reference level for 1000-nit HDR10 content. This results in washed-out midtones and limited dynamic range, reducing the overall HDR impact. Furthermore, the paper white slider becomes less predictable due to different max tone mapping luminance values, which adds an extra layer of complexity to setting it up as well.

To improve HDR visuals, using an HGIG-supported TV is recommended. For non-HGIG displays, setting max TML to 1000 nits and paper white to around 200 nits offers a reasonable balance. Enabling the console’s dark theme could be helpful for better brightness control on OLEDs. It is recommended to restrict the HDR output to “compatible software only” to avoid any unnecessary HDR conversion. Screen burn-in protection should also be disabled since it does nothing useful on most displays.
