After JayzTwoCents unveiled the live photos of the upcoming Radeon RX 6900XT, another YouTuber RedGamingTech has totally leaked the photos of this upcoming GPU. It seems both the YouTubers share the same source that asked RedGamingTech to leak almost all the photos of the reference GPU.
Yes its the same triple-fan GPU which has been unveiled on Fortnite and AMD has even previewed it on Twitter. But these YouTubers have taken into the next level even showing the backside of the GPU. Although the name Radeon RX 6900XT has not been confirmed yet this is surely the next flagship RDNA 2 based AMD GPU.
AMD will be launching multiple Navi 2x GPUs to counter NVIDIA’s new RTX 30 series GPUs and the flagship model shown here should feature Navi 21 GPU while the other should be Navi 22 or Navi 23 based. The Radeon RX 6900 series features the same revamped RADEON logo that will glow in red.
Also, there’s a large cut out on the sides of the GPU for the fans to ventilate the hot air. With the ‘R’ logo on the top of each fan, there are two 8-pin power connectors meaning a lot of power will be needed to power these GPUs. For the ports, you have four display outputs including 1 HDMI, 2 DisplayPort, and a single Virtual Link port (Type-C) connector.
The image for the dual-fan AMD GPU, probably the Radeon RX 6800 & Radeon RX 6700 series of GPUs, is also the same. The dual-fan design has the same design but slightly different cooling solutions and a slightly compact form factor. The dual axial-tech fan design features a large “R” logo in the middle as well as on the fans too that symbolizes the Radeon branding.
Source: RedGamingTech Source: RedGamingTech
Interestingly, apart from the reference GPUs, RedGamingTech also shared two images of other AIB cards as well, one being a dual-fan one probably the Radeon RX 6800 or Radeon RX 6700, and also there’s a triple-fan GPU as well which should be the AMD Radeon RX 6900XT.
You can check RedGamingTech‘s video as well for more reference and he also mentioned that he had few more images but does not have the authority to share them. He also even stated the fact that the dual-fan design image could actually change as well before launch.
Leaking out this much info before over 1 month left for launch doesn’t make sense, however, maybe AMD maybe wants to keep some gamers towards itself who can tend to go for NVIDIA instead. Well, honestly seeing this much hardware is too pleasant for my eyes and this will actually be interesting to see if RDNA 2 lives up to the hype that its has created in the market.
