NVIDIA announced its 2nd Generation DGX Station AI server. The server is based on companies latest Ampere A100 Tensor Core GPUs. The A100 is aimed at the fastest growing AI market and is designed to accelerate machine learning and data science performance.
Four A100 Tensor Core GPUs power the A100. The Tensor Core GPUs in A100 comes with 80 GB of HBM2e memory. It is twice the memory of the original A100. DGX Station has a total of 320 GB of total memory capacity. It supports the 3rd Gen NVLink support and offers 200 GB/s of bidirectional bandwidth.
The system, however, is powered by AMD EPYC Rome 64 Core CPU. It comes with PCIe Gen 4 support along with 512 GB of dedicated system memory. Not to mention the 1.92 TB NVME M.2 SSD storage and 7.68 TB NVME U.2 SSD storage.
The rest of specifications of the 2nd Generation DGX Station remains the same.
NVIDIA Ampere GA100 GPU Specs:
| NVIDIA Tesla Graphics Card | Tesla K40 (PCI-Express) | Tesla M40 (PCI-Express) | Tesla P100 (PCI-Express) | Tesla P100 (SXM2) | Tesla V100 (SXM2) | Tesla V100S (PCIe) | NVIDIA A100 (SXM4) | NVIDIA A100 (PCIe4) |
| GPU | GK110 (Kepler) | GM200 (Maxwell) | GP100 (Pascal) | GP100 (Pascal) | GV100 (Volta) | GV100 (Volta) | GA100 (Ampere) | GA100 (Ampere) |
| Process Node | 28nm | 28nm | 16nm | 16nm | 12nm | 12nm | 7nm | 7nm |
| Transistors | 7.1 Billion | 8 Billion | 15.3 Billion | 15.3 Billion | 21.1 Billion | 21.1 Billion | 54.2 Billion | 54.2 Billion |
| GPU Die Size | 551 mm2 | 601 mm2 | 610 mm2 | 610 mm2 | 815mm2 | 815mm2 | 826mm2 | 826mm2 |
| SMs | 15 | 24 | 56 | 56 | 80 | 80 | 108 | 108 |
| TPCs | 15 | 24 | 28 | 28 | 40 | 40 | 54 | 54 |
| FP32 CUDA Cores Per SM | 192 | 128 | 64 | 64 | 64 | 64 | 64 | 64 |
| FP64 CUDA Cores / SM | 64 | 4 | 32 | 32 | 32 | 32 | 32 | 32 |
| FP32 CUDA Cores | 2880 | 3072 | 3584 | 3584 | 5120 | 5120 | 6912 | 6912 |
| FP64 CUDA Cores | 960 | 96 | 1792 | 1792 | 2560 | 2560 | 3456 | 3456 |
| Tensor Cores | N/A | N/A | N/A | N/A | 640 | 640 | 432 | 432 |
| Texture Units | 240 | 192 | 224 | 224 | 320 | 320 | 432 | 432 |
| Boost Clock | 875 MHz | 1114 MHz | 1329MHz | 1480 MHz | 1530 MHz | 1601 MHz | 1410 MHz | 1410 MHz |
| TOPs (DNN/AI) | N/A | N/A | N/A | N/A | 125 TOPs | 130 TOPs | 1248 TOPs 2496 TOPs with Sparsity | 1248 TOPs 2496 TOPs with Sparsity |
| FP16 Compute | N/A | N/A | 18.7 TFLOPs | 21.2 TFLOPs | 30.4 TFLOPs | 32.8 TFLOPs | 312 TFLOPs 624 TFLOPs with Sparsity | 312 TFLOPs 624 TFLOPs with Sparsity |
| FP32 Compute | 5.04 TFLOPs | 6.8 TFLOPs | 10.0 TFLOPs | 10.6 TFLOPs | 15.7 TFLOPs | 16.4 TFLOPs | 156 TFLOPs (19.5 TFLOPs standard) | 156 TFLOPs (19.5 TFLOPs standard) |
| FP64 Compute | 1.68 TFLOPs | 0.2 TFLOPs | 4.7 TFLOPs | 5.30 TFLOPs | 7.80 TFLOPs | 8.2 TFLOPs | 19.5 TFLOPs (9.7 TFLOPs standard) | 19.5 TFLOPs (9.7 TFLOPs standard) |
| Memory Interface | 384-bit GDDR5 | 384-bit GDDR5 | 4096-bit HBM2 | 4096-bit HBM2 | 4096-bit HBM2 | 4096-bit HBM2 | 6144-bit HBM2e | 6144-bit HBM2e |
| Memory Size | 12 GB GDDR5 @ 288 GB/s | 24 GB GDDR5 @ 288 GB/s | 16 GB HBM2 @ 732 GB/s 12 GB HBM2 @ 549 GB/s | 16 GB HBM2 @ 732 GB/s | 16 GB HBM2 @ 900 GB/s | 16 GB HBM2 @ 1134 GB/s | 40 GB HBM2 @ 1.6 TB/s | Up To 80 GB HBM2 @ 1.6 TB/s |
| L2 Cache Size | 1536 KB | 3072 KB | 4096 KB | 4096 KB | 6144 KB | 6144 KB | 40960 KB | 40960 KB |
| TDP | 235W | 250W | 250W | 300W | 300W | 250W | 400W | 250W |
