Lenovo’s ThinkPad X1 Nano was first announced in late September 2020, and the release date was given beyond the 4th quarter of 2020. Now it means that the machine will be launched in December or most probably in early 2021. The speculation on the internet is which 11th gen CPU is included in the device.
There are two kinds of Tiger Lake U processors, UP3 and UP4. The UP3 CPUs have a TDP of 12 to 28 W, while the UP4 processors can consume 7 to 15 W. In the Spec sheet below, Lenovo only conforms that the ThinkPad X1 nano has 11th gen intel core-i7 processor, but the model is not specified.
According to sources, the X1 Nano will feature the lower-powered UP4 Tiger Lake variant. Probably the model here will be the Intel Core i7-1180G7. The chip can reach the maximum TPD of 15 W.
The detailed spec of the device is given below:
| Processor | Up to 11th Gen Intel® Core™ i7 |
| Operating System | Up to Windows 10 Pro Linux |
| Display | 13″ 2K Touchscreen (2160 x 1350) with Dolby Vision™, 450 nits, 100% sRGB 13″ 2K (2160 x 1350) with Dolby Vision™, 450 nits, 100% sRGB |
| Memory | Up to 16GB LPDDR4x |
| Battery | Up to 17.3 hours*, 48Wh (MM14) Up to 13 hours* (MM18) Rapid Charge included |
| Storage | Up to 1TB PCIe SSD |
| Graphics | Intel® Iris® Xe |
| Security | Discrete Trusted Platform Module (TPM) 2.0 Human-presence detection with Windows Hello & IR camera Match-on-chip fingerprint reader Webcam privacy cover |
| Audio | Dolby Atmos® Speaker System 4 x 360-degree mics |
| Camera | Hybrid infrared (IR) / 720p HD with webcam privacy cover |
| Dimensions (H x W x D) | 13.87mm x 292.8mm x 207.7mm / 0.55″ x 11.5″ x 8.15″ |
| Weight | Starting at 907g / 1.99lbs |
| Color | Black Black with Carbon-Fiber Weave on top cover (available on Touch models only) |
| Certifications | Energy Star® 8.0 EPEAT® Gold |
| Connectivity | Optional: WWAN LTE 5G / LTE 4G CAT9* WLAN: WiFi 6 AX201 / 802.11 AX Bluetooth® 5.0 |
| Ports / Slots | 2 x Thunderbolt™ 4 Headphone / mic combo |
| Keyboard | Spill-resistant Backlit with white LED lighting Call-control keys (F9-F11) |
| Power Supply Unit | USB-C 65W (supports rapid-charging technology) |
| Supported Docking | ThinkPad Thunderbolt 3 Dock Gen 2 Docking stations are sold separately. |
