EVGA and ZOTAC prepared NVIDIA GeForce RTX 3060 Ti custom models have been leaked with some juicy spec details. The EVGA GeForce RTX 3060 Ti will come in at least three flavours within its FTW3 and XC3 lineup. The FTW3 variant will have a dual-slot & triple-fan cooling system. The PCB is custom-made and will also feature a dense aluminium heatsink. The heatsink reportedly contacts the GPU, VRAM, and VRMs.
Via VideoCardz
The manufacturer is providing five thick copper heat pipes within FTW3 models and the exhaust vents on the back of the backplate. The PCB comes with cut-outs to let air channel through and out of the exhaust vents on the back.
via VideoCardz
The XC3 variant comes with a dual-slot and dual-fan configuration. The card will feature a full-length PCB and cut-out vents on both the PCB and the backplate. It also features a large
According to sources, the ZOTAC GeForce RTX Twin Edge comes in standard and OC variants. The card is a dual-slot and dual-fan configuration. It comes with a cooler/backplate and a custom PCB. It has a single 8-pin connector and also features a large aluminium heatsink with multiple heat pipes.
NVIDIA GeForce RTX 30 Series Specs:
| Graphics Card Name | NVIDIA GeForce RTX 3050 | NVIDIA GeForce RTX 3050 Ti | NVIDIA GeForce RTX 3060 | NVIDIA GeForce RTX 3060 Ti | NVIDIA GeForce RTX 3070 | NVIDIA GeForce RTX 3070 Ti? | NVIDIA GeForce RTX 3080 | NVIDIA GeForce RTX 3080 Ti? | NVIDIA GeForce RTX 3090 |
| GPU Name | Ampere GA107 | Ampere GA106? | Ampere GA106? | Ampere GA104-200 | Ampere GA104-300 | Ampere GA102-150 | Ampere GA102-200 | Ampere GA102-250 | Ampere GA102-300 |
| Process Node | Samsung 8nm | Samsung 8nm | Samsung 8nm | Samsung 8nm | Samsung 8nm | Samsung 8nm | Samsung 8nm | Samsung 8nm | Samsung 8nm |
| Die Size | TBA | TBA | TBA | 395.2mm2 | 395.2mm2 | 628.4mm2 | 628.4mm2 | 628.4mm2 | 628.4mm2 |
| Transistors | TBA | TBA | TBA | 17.4 Billion | 17.4 Billion | 28 Billion | 28 Billion | 28 Billion | 28 Billion |
| CUDA Cores | 2304 | 3584 | 3840 | 4864 | 5888 | 7424 | 8704 | 10496 | 10496 |
| TMUs / ROPs | TBA | TBA | TBA | 152 / 80 | 184 / 96 | 232 / 80 | 272 / 96 | 328 / 112 | 328 / 112 |
| Tensor / RT Cores | TBA | TBA | TBA | 152 / 38 | 184 / 46 | 232 / 58 | 272 / 68 | 328 / 82 | 328 / 82 |
| Base Clock | TBA | TBA | TBA | 1410 MHz | 1500 MHz | TBA | 1440 MHz | TBA | 1400 MHz |
| Boost Clock | TBA | TBA | TBA | 1665 MHz | 1730 MHz | TBA | 1710 MHz | TBA | 1700 MHz |
| FP32 Compute | TBA | TBA | TBA | 16.2 TFLOPs | 20 TFLOPs | TBA | 30 TFLOPs | TBA | 36 TFLOPs |
| RT TFLOPs | TBA | TBA | TBA | 32.4 TFLOPs | 40 TFLOPs | TBA | 58 TFLOPs | TBA | 69 TFLOPs |
| Tensor-TOPs | TBA | TBA | TBA | TBA | 163 TOPs | TBA | 238 TOPs | TBA | 285 TOPs |
| Memory Capacity | 4 GB GDDR6? | 6 GB GDDR6? | 6 GB GDDR6? | 8 GB GDDR6 | 8 GB GDDR6 | 10 GB GDDR6X? | 10 GB GDDR6X | 20 GB GDDR6X | 24 GB GDDR6X |
| Memory Bus | 128-bit | 192-bit? | 192-bit? | 256-bit | 256-bit | 320-bit | 320-bit | 320-bit | 384-bit |
| Memory Speed | TBA | TBA | TBA | 14 Gbps | 14 Gbps | TBA | 19 Gbps | 19 Gbps | 19.5 Gbps |
| Bandwidth | TBA | TBA | TBA | 448 Gbps | 448 Gbps | TBA | 760 Gbps | 760 Gbps | 936 Gbps |
| TGP | 90W? | TBA | TBA | 180W? | 220W | 320W? | 320W | 320W | 350W |
| Price (MSRP / FE) | $149? | $199? | $299? | $399 US? | $499 US | $599 US? | $699 US | $899 US? | $1499 US |
| Launch (Availability) | 2021? | 2021? | 2021? | November 2020? | 29th October | Q4 2020? | 17th September | January 2021? | 24th September |
